MSchemV is an up-and-coming program for viewing MCEdit-compatible Schematic files. It is a work in progress, but I have decided to release an early alpha so that I can get feedback on what direction I should take this program in.sp:�wee

Bare in mind please that this is an early release. The final product will differ greatly from this version, and is only to help steer the development into something that the community wants.

This is actually ported over from an earlier attempt of mine named MSchemV - this program's specific codename is actually wxMSchemV, as it is written using the wxWidgets library, is completely in C++ and as such is cross-platform. I plan to make this available to Macs and Linux machines when it is ready for release.

If I forget the download link:
http://alteredsoftworks.com/mschemv/latest/

Requirements:

Features:
  • Texture pack support
  • MCEdit .schematic support
  • Zooming, maneuvering
  • OpenGL for fast, clean rendering
  • 3D perspective rendering test
  • First person movement
  • VBO support
  • Scripting support for blocks (0.0.0.6)

Todo:
  • Re-implement "Count Blocks" feature
  • Re-implement "Grid" feature
  • Re-implement version update check feature
  • Re-implement viewports
  • Refactor threading code (move threading to RendererBase out of control - have Control simply mirror/hook RenderFinished)
  • Mac/Linux ports
  • World support?
  • Entity support
  • Support texture pack folders

I would love some opinions on direction and where to take MSchemV.

Thank you, PMC community, for providing me the opportunity to show off and have you guys aid development.
Progress: 30% Complete
Game Version:Minecraft 1.4
Tags:Schematic, Viewing, Program, Awesome
Credit:Ragnur_Le_Barbare (ship), Conquer, Dollars (icon)

Update #5 : 12/30/2012 7:33:19 pm12/30/12

Updated to 0.0.0.6.

This version sports many bugfixes, as well as a brand new feature: scripts! Mod makers can now write scripts to support their own blocks. Check the scripting documentation to learn more about this. :)

Update #4 : 12/25/2012 12:13:51 pm12/25/12

Updated to 0.0.0.5. Something of an emergency intermediate update, because I realized that the x axis was flipped. All of the blocks render properly now.

Update #3 : 12/22/2012 11:11:04 pm12/22/12

Version 0.0.0.4 is ready.

I changed the 3D view to be perspective instead of orthographic. You can click & hold on the view and use the arrow keys to explore.

Texture packs are fixed - they suffered a bug in 0.0.0.3- where they borked if you switched too much. Also added VBO support; those with VBO support on GPUs will notice like a 500% speed increase in rendering.

Update #2 : 12/22/2012 10:39:31 am12/22/12

A little emergency update to solve a few problems I noticed after releasing it. I reduced the amount of the thread waiting for the UI thread and vice versa; made a few more things 'safer' for transfer. As a result, the rendering is almost entirely flawless in terms of rotating/layering while it is still rendering.

Update #1 : 12/22/2012 8:44:40 am12/22/12

First update. Woo.
  • Implemented basic 3D view, as well as re-writing all of the block renderers in 3D. Why didn't I do this to begin with. These mysteries and more on the next Unsolved Mysteries, narrated by Mystery.
  • See main post Features/Todo for more details.
