Panzerkampfwagen Tiger Ausf. B
Tiger II (King Tiger) Minecraft MapTiger II tank on paved street in Budapest, October 1944
TypeHeavy tank
Place of originNazi Germany
Service history
In service1944–1945
WarsWorld War II
Production history
DesignerHenschel & Son / Krupp (turret)
Designed1943
ManufacturerHenschel & Son / Krupp (turret)
Unit cost800,000 Reichsmark ($300,000 USD) in 1944-1945[1]
Produced1943–1945
No. built492[2]
Specifications
Mass68.5 tonnes (67.4 long tons; 75.5 short tons) (early turret)
69.8 tonnes (68.7 long tons; 76.9 short tons) (production turret)[3]
Length7.38 metres (24 ft 3 in) (hull)
10.286 metres (33 ft 9 in) (with gun forward)[3]
Width3.755 metres (12 ft 4 in)[3]
Height3.09 metres (10 ft 2 in)[3]
Crew5 (commander, gunner, loader, radio operator, driver)

Armor25–185 mm (1–7 in)[3]
Main
armament
8.8 cm KwK 43 L/71
Early Krupp design turret: 80 rounds[4]
Production turret: 86 rounds[4]
Secondary
armament
7.92 mm Maschinengewehr 34
5,850 rounds[3]
EngineV-12 Maybach HL 230 P30gasoline
700 PS (690 hp, 515 kW)[5]
Power/weight10 PS (7.5 kW) /tonne (8.97 hp/tonne)
TransmissionMaybach OLVAR EG 40 12 16 B (8 forward and 4 reverse)[5]
Suspensiontorsion-bar
Ground clearance495 to 510 mm (1 ft 7.5 in to 1 ft 8.1 in)[3]
Fuel capacity860 litres (190 imp gal)[3]
Operational
range
Road: 170 km (110 mi)[6]
Cross country: 120 km (75 mi)[6]
SpeedMaximum, road: 41.5 km/h (25.8 mph)[6]
Sustained, road: 38 km/h (24 mph)[6]
Cross country: 15 to 20 km/h (9.3 to 12.4 mph)[6]
Progress100% complete
