Custom World Generation is an experimental feature, allowing a data pack to generate custom features, biomes, or dimensions, primarily by way of a series of JSON files rather than by using commands.
This guide goes over how to create every step of a Custom Dimension, which itself comprises all of the following. If you only want to achieve one or some of these things, you can generally skip to those respective sections.
- Modifying and defining dimension settings
- Generating terrain
- Creating biomes
- Arranging biomes
- Creating features (ores, trees, etc.)
- Many sub-tasks related to the above
landscape What is Custom World Generation?
Custom Worldgen can take the form of anything from a completely separate dimension, an override of vanilla dimensions or biomes, like the Overworld at large or Swamps in particular, or individual features that are placed via commands. The following are all things that Custom World Generation can include, irrespective of difficulty.- Custom Terrain
- Custom Dimension Settings, such as:
- Ultrawarm
- Piglin zombification
- Respawn Anchors vs Beds
- Light level
- Daylight cycle (on/off)
- etc.
- Custom Biomes (Surface and Cave)
- Natural features (Trees, ores, flowers, etc.)
- Custom colors and ambient particles
- Custom Biome layout (including of vanilla biomes)
folder Folder Structure
To begin creating a Custom Dimension, there are a few folders you should create in a data pack. If you’re unfamiliar with the general structure of a data pack, check out some of our other blogs.In your namespace folder, you will create the following folders, organized as such:
<namespace>
(functions)
dimension
dimension_type
worldgen
biome
configured_carver
configured_feature
density_function
noise
noise_settings
placed_featureYou may not need all of these folders depending on the degree of configurability you want or the scope of your project, so which folders are needed or optional for any particular task will be listed at the top of each section.
Because Custom World Generation requires so many different JSON files, many with a variety of required vs. optional fields, it is strongly recommended that you generate most or all of these files using Misode’s generators. Furthermore, frequent reference to the wiki pages for custom dimensions and their respective subcategories will likely be necessary, if only to determine what type of data some fields are expecting, when Misode or this guide do not specify.
One final note: Some popular VSCode extensions may falsely inform you that certain files you reference don’t exist or are in the wrong folder, when in fact they are, depending on the version you are working in. This is most common for configured_features, but be on the lookout for this behavior elsewhere.
Dimension Type
Folders: dimension_typeWhen creating a new dimension, or modifying an existing one, it’s recommended to start with the Dimension Type. The Dimension Type is what defines the very broad details about the dimension, such as whether water evaporates instantly like the Nether (Ultrawarm), whether Beds and/or Respawn Anchors work or explode, and what light level Hostile Mobs need to spawn. Most of these fields are self explanatory, and most of them are required.
To create this, simply add a .json file to the dimension_type folder, and set the name to that of the dimension you are creating/modifying. Like all file names, it must have no capital letters, and no special characters except underscores. Then generate the list of fields with Misode.
Note that some fields, like “has ceiling”, don’t do what you would expect–this field doesn’t actually give the dimension a physical ceiling, that’s handled in the terrain. Similarly, “Effects” pretty much just changes the skybox and determines whether the time affects the light level.
Noise Settings
Folders: noise_settingsOptional Folders: density_function, noise
The Noise Settings are one of the largest files you will create. This single file per dimension controls all of the following:
- What base block the dimension’s terrain is made of (Stone, Netherrack, etc.)
- What base fluid is used for the sea level (Water, Lava, etc. Does not need to be a fluid)
- Some global settings, such as:
- Whether “Creatures” (passive mobs) spawn during chunk generation
- Biome noise parameters that the worldspawn is allowed to be set in during world creation
- Whether large ore veins generate, and their general size and shape via Density Functions. Only applies to Copper and Iron veins
- Whether aquifers generate. Not configurable beyond true/false.
- If false, most caves below sea level will be filled with the base fluid.
- Noise Router (The shape of the terrain, which is determined by a few further fields)
- Surface Rules (What blocks the surface is made up of, typically broken down by biome)
Noise Router (Terrain)
The Noise Router is responsible for most factors relating to the terrain, which is to say, whether a given block is air/fluid or the default_block, before surface_rules or biome features are added. In addition, the Noise Router includes several fields that don’t directly influence the terrain, but may approximate it for use in making biome distribution conform to the terrain.
The Noise Router contains several fields. All of these fields are density functions, which can be defined in-line or referenced from the density_function folder. These are essentially formulas of variable length and complexity, that use a variety of functions to determine a value between 0 and 1 for every coordinate. For density functions that affect terrain, this determines whether the block is air/fluid (respecting sea level), or the default_block, respectively.
Let’s look at what each of these density functions are responsible for.
barrier, fluid_level_floodedness, fluid_level_spread: These all relate to some facet of Aquifer generation, if they are enabled.
lava: Used to determine whether an aquifer is lava or not. Does not affect the lava that floods the bottom of the world.
vein_toggle, vein_ridged, vein_gap: Used to control the shape, density, and rarity of both Iron and Copper Large Ore Veins. Cannot change what these blocks are made of, but whether the vein is Copper or Iron is based on the vein_toggle noise range.
temperature, vegetation, ridges: Correspond to the “temperature,” “humidity,” and “weirdness” parameters in the dimension’s biome source, respectively. Ostensibly create the noise maps that biomes are placed relative to. These density functions don’t affect terrain at all.
continents, erosion, depth: Correspond to the “continentalness,” “erosion,” and “depth” parameters in the dimension’s biome source, respectively. Like the temperature, vegetation, and ridges density functions, these don’t affect terrain at all and ostensibly just create noise maps for the biome source to use. However, in the vanilla overworld, these density functions are specifically calibrated to more or less mirror the actual terrain, so that biomes can be placed relative to terrain.
For example, the erosion density function is calibrated such that high values match up with where the terrain is more flat. It doesn’t directly make the terrain flatter (though the density_function file of this name may be referenced in part of the Noise Router that does directly impact terrain).
It’s worth noting that temperature, vegetation, and ridges are also all capable of behaving more like continents, erosion, and depth, but it’s generally not necessary to have so many parameters that conform to terrain, and can in fact make biome distribution harder and more time consuming.
initial_density_without_jaggedness: Used for aquifers and surface_rules, in order to more accurately determine where the surface of the world is so that neither can generate above that surface. Typically, should be lower than final_density. Similar to the above few functions, it does not affect terrain at all.
final_density: This is the density function that actually creates the bulk of the terrain. As such, it’s often the largest and most complex part of the noise_settings file, barring surface_rules. It controls not only the surface, including hills, mountains, valleys, and oceans, but also the large noise caves and noodle caves introduced in the Caves and Cliffs update. And, as alluded to above, you still need at least the continents and erosion density functions to align with the general shape of this density function if you plan to have ocean biomes generate only where the terrain dips below sea level, or mountain biomes generate only where the terrain spikes up to look like mountains.
All of this culminates in Custom Terrain being incredibly time-consuming to craft and get just right, if you want to have Mountains, Oceans, and noise caves, and especially if you want those Mountains and Oceans to actually be able to have biomes mapped onto them.
Density functions themselves are far too complex to get a good feel for without just messing around with them, so it’s recommended to do so using Misode (either the Density Function feature, or the Noise Settings feature). This brief tutorial, written by Misode and now hosted on the wiki, will explain how the Final Density affects the terrain, and some basic steps to manipulate it. It does not provide significant detail, and unfortunately, such detail is outside the scope of this blog. Currently, the best way to learn and create custom terrain is by fiddling with these density functions via Misode’s generator.
Surface Rules
Surface Rules are what add the surface layers to terrain. This is highly-configurable, but at its most basic level, it’s what decides that the ground in Forests is made up of Grass Blocks and Dirt, and that Deserts have Sand and Sandstone. Surface Rules can also allow for different blocks to make up the ground depending on height, steepness, or even based on random noise.Notably, the Surface Rule also places the Bedrock on the bottom (or top) of the world, and handles the transition from Stone to Deepslate at Y=0. This means both of these features can be edited or removed, and in fact it’s fairly easy to do so compared to handling the actual surface.
Creating surface rules is relatively easy. You’ll start with something like this in your Noise Settings:
"surface_rule": {
"type": "minecraft:sequence",
"sequence": []
}Inside the sequence brackets, you can add yet more objects. There are four different types:- Sequence: Allows you to add a new nested list. Generally, it’s good practice to nest sequences inside of a condition that will apply to multiple child conditions or blocks.
- Block: Defines the block that gets placed. Usually used at the end of a series of conditions.
- Bandlands: Not a typo. Just places the hardcoded Badlands terracotta pattern, and doesn’t have any additional fields.
- Condition: This is the most prominent part of Surface Rules. There are multiple kinds of conditions, including biome, Y level, steep, and more. Regardless of the condition you select, it will always have the additional field “then run”, which just accepts another object type from the above list.
above_preliminary_surface: Uses the initial_density_without_jaggedness density function to determine where the surface of the world is. Not using this would just mean that the surface rule would apply in noise caves as well. If you’re not using an initial_density_without_jaggedness density function, there’s no other real harm in choosing not to use this condition.
stone_depth: This condition finds the blocks that are actually on the surface via heightmap, ignoring water, and works even if there was no preliminary surface condition used. This is one of the most common conditions, in that every dimension will use it, but it is also a fairly resource-intensive condition, and the one most likely to cause chunk generation lag. It’s best to use it minimally, as high up in the Surface Rule as you can. Oftentimes, you will need at least two of these: One for the top surface, and one for the secondary surface.
water: Can be used to have its child conditions apply based on the fluid level at that location, including not being in fluid. The vanilla Overworld surface rule uses this a lot, and it’s a great way to alleviate the impact of an earlier stone_depth condition.
biome: Specifies which biome(s) to apply the rest of the rule to.
y_above: Causes the rest of the rule to only apply to blocks above the specified Y value. You can add an optional multiplier for this value, or choose to add the stone_depth from previous conditions to this calculation.
It’s best to look at how the Overworld’s surface rule uses combinations of conditions to produce a surface of, for example, Grass Blocks with 2-4 layers of Dirt underneath. The vanilla Overworld Surface Rule is not as extreme as the vanilla Overworld Dimension file (up next), but it is a little more lengthy and sophisticated than can reasonably be pasted here. Misode’s generator has a feature to view the vanilla Overworld Noise Settings as a preset, which includes the Surface Rule; this may be useful to get a more user-friendly view of how the conditions fit together.
Dimension
Folders: dimensionThe Dimension file is where you reference both the Dimension Type and Noise Settings you would like this dimension to use by their namespaced ID. The name of this file is also what will become the namespaced ID of this dimension for commands such as /execute in, regardless of the names of the noise_settings or dimension_type files referenced. Lastly, this is where you will list all of the biomes you want to appear in the world, using parameters to define which biomes can appear where on several noise maps.
Biome Source
Besides Terrain, the Biome Source is where you may find yourself spending the most time. It is highly configurable, and has the potential to integrate with the Continents and Erosion density functions defined in the Noise Router to help place biomes in a way that appears to conform to the terrain (Mountain biomes on elevated terrain, Plains biomes on flatter terrain, etc.). Biome Layout is much more approachable than terrain in terms of configurability, but making them work hand-in-hand in this way can be time consuming.To put things in perspective, you may have noticed above that the vanilla Overworld’s Dimension file is over 200,000 lines long. Every biome has dozens of repeat entries, each with slightly different parameters, honed over the course of several months to get the biome distribution and terrain conformity just right. As such, the following tasks may be extremely time consuming, if not very difficult:
- Adding a new biome to the existing Overworld
- Tweaking the biome layout of the Overworld
The End’s biome source is hardcoded; this is because Mojang needs to ensure that the central End Island is always the default “minecraft:the_end” biome, which cannot be guaranteed with current tools. However, if you don’t mind making the central End Island a different biome, you can approach a custom biome layout similarly to how you would the Nether.
For a custom dimension, the complexity is up to you. If you aim to have your biomes conform to terrain, then you may end up with a biome layout of comparable complexity and time commitment to the vanilla Overworld’s. If not, then it’s just a matter of determining which biomes you do or do not want to appear next to each other, and then setting the parameters appropriately.
Each entry in the “biomes” list should look something like this:
More biomes can be added by including more entries in the “biomes” list. It can and often may include repeats. Each entry must also contain all of the parameters listed above.
Parameters
Unless otherwise specified, all of these parameters can either be a single constant, or a list of two constants, which serves as a min and max range of values. These must be in order from min to max; failure to do so will cause the data pack to not validate.“temperature”, “humidity”, and “weirdness”: These are all named completely arbitrarily, and have no bearing on the actual temperature or humidity of the biome that impacts gameplay in any way. You can make both a “desert” and “snowy” biome have a temperature of 0, and all it will mean is that they will be placed near each other (unless other parameters forbid this). These parameters just refer to different noise maps that are available. These should each be a value between -1.0 and 1.0. The closer a value is to 0, the more frequently that biome will appear, or the larger.
“depth”: Used exclusively for cave biomes, and is otherwise 0. Positive values cause that biome to be placed deeper in the world, and the area above it to be filled with other biomes of lower depth values that meet the other parameters of that space. In the vanilla depth density function, a depth of 1.0 corresponds to approximately 128 blocks below the surface, but this can vary if you've changed the Final Density or the depth density function in your Noise Router.
“offset”: Helps to limit the relative size of the biome. Accepts a value between 0 and 1.0, and must be a single constant, not a list. Larger values reduce the size of the biome, and allow biomes of neighboring parameter values to fill the space. This can also result in the biome becoming rarer, if it was already small enough that a positive offset causes some of its placements to disappear.
“continentalness” and “erosion”: These are the two parameters that influence a biome’s placement on the density functions of the same names used for Terrain. In the vanilla Overworld, only these values will affect biome position relative to the shape of the terrain. For the vanilla Overworld:
- High continentalness corresponds to inlands terrain.
- Low continentalness corresponds to ocean terrain.
- High erosion corresponds to flat terrain.
- Low erosion corresponds to jagged terrain.
The best way to view and manipulate the biome source and how it may look in the world is with Misode’s generator. However, it may not show completely accurate biome placement if you are taking advantage of continentalness and/or erosion.
Biomes
Folders: biomeOptional Folders: configured_carver, placed_feature, configured_feature
This is where the most configurability and excitement, and least limitations, comes into play. Biomes are really just designated areas that can have the following things defined:
- Precipitation (True/False)
- Temperature
- Used to determine rain or snow if Precipitation is true
- Also influences natural grass and foliage coloration, along with Downfall
- Override colors for grass, foliage, sky, fog, water, and water fog
- Note for grass and foliage, this color is added to the color determined by Temperature and Downfall, which references the respective colormaps in the Resource Pack
- Particles, if any (such as in many Nether biomes)
- Music and ambient sounds
- Cave and canyon (ravine) types
- Naturally spawning mobs
- Features
Important to note, if you are modifying a vanilla biome (or a biome from another mod or data pack), your biome will necessarily be incompatible with any other data packs that modify that biome, too. This means you can’t, for example, add more Diamonds to the vanilla Swamp biome, and then also include Terralith -- you would need to instead use Terralith’s Swamp biome as a base and add more diamonds to that, if you want to use both in the same world.
Naturally Spawning Mobs
Called “Spawners”, (not confusing at all) this is what decides what mobs will spawn in this biome, at what rarities and in what quantities.Note that this does not dictate those mobs’ spawning conditions–for the most part, we can’t change that. Passive Mobs will always need Grass Blocks and light to spawn, and Hostile Mobs will still need a low enough light level as defined in the Dimension Type. Some mobs, like Sniffers and Camels, don’t have as strict spawning conditions because they don’t spawn naturally in vanilla. This means they can spawn anywhere in the biome, even if it doesn’t make sense.
Spawners are defined by first opening up a list of one of several categories, such as Monster, Creature, Water Ambient, or Axolotl. You can make mobs spawn in whatever category you want, but if you put it in the wrong category than it belongs (generally, Creature for passive mobs, Monster for hostile mobs, etc.), they may either fail to spawn entirely, or overspawn and exceed the mobcap. For this reason, it is advised that you only spawn mobs in their correct category; if you don’t know which it belongs to, refer to a vanilla biome that spawns that mob and see where it’s placed.
An individual mob spawner entry includes the mob type, its weight (which works just like loot tables) and a min and max count. These latter values determine how many mobs will spawn within a group as one successful spawn attempt of that mob type. The min must be greater than 0.
Spawn Costs
Spawn Costs are an optional field within the biome file, and are used to limit the frequency of spawns around mobs of a certain type, within that biome only. In vanilla, this is used to limit the number of Endermen that appear in Warped Forests, and Skeletons that appear in Soul Sand Valleys.
A Spawn Cost for an individual mob consists of an energy_budget, and a charge, which are both float values. These are a little hard to explain, but essentially, the “charge” is used to calculate an individual mob’s contribution to the overall “energy budget” shared by all mobs of that type in the biome. If the value calculated from that charge would exceed that energy budget, it fails to spawn. This is very simplified, and indeed somewhat unintuitive, as the charge will generally be higher than the energy budget.
If you’d like to learn more about how this works, see the wiki entry relating to it here.
Carvers
This is where the legacy caves and ravines are defined for the biome. They are split into two steps: air and liquid, which behave as you would expect; either producing regular air caves, or flooded caves.You can define custom caves or canyons with a configured_carver, including defining what types of blocks the cave will be allowed to replace (which is why it’s called a carver), their frequency, size, and other values. To explore this fully, it’s recommended to mess with the various fields using Misode’s generator.
Features
Features are the real meat of a biome. These are everything that actually fills up the biome and gives it character beyond the terrain and surface. Trees, flowers, ores, geodes, granite deposits, and sometimes small structures like Desert Wells are all features. There is a lot you can do here, but the options aren’t limitless.For one, there’s the issue of performance. Larger and more common features make loading new chunks slower, as do features that have hyper-specific location requirements to spawn.
For two, some specific shapes are harder to achieve, and some common features aren’t as configurable as others. Trees are some of the most configurable features in the game, able to use any block or combination of blocks for their trunks, leaves, roots, and more, and can be used to make elaborate shapes and features that don’t even look like trees. Conversely, the coral reefs in Warm Oceans are easy to replicate and adjust the frequency and location of, but their shapes and the blocks they’re made of cannot be changed at all.
As such, it’s often better to have some broad strokes for the “feel” or atmosphere you want for a biome in mind, rather than planning everything down to the shape, as flexibility may be necessary.
Best practice is to have the “features” section of your biome consist of 11 lists (defined with square brackets: [ ]), called “steps”, but you can have any number of steps, fewer or greater. Generally, features will be placed in order based on which step they appear in, from top to bottom. So, if you want to place Tree features with leaves made of Stone, and then place Ore features that get placed in the stone, you would put those features in separate steps, with the Ore feature in a later step from the Tree.
Other parts of the game refer to these steps by name, representative of the order they generate in, specifically for things like Custom Structure Generation to reference which step of generation those should appear in. However, the names themselves are arbitrary and just reflect which steps vanilla chooses to put its features in; any feature type can go in any step. For interest’s sake, these designations are, in order from first step to last:
- RAW_GENERATION: Where End biomes place the small circular endstone islands
- LAKES: Where Overworld biomes place lava lakes, and used to place water lakes
- LOCAL_MODIFICATIONS: Where Overworld Biomes place Amethyst Geodes, and the Frozen Ocean biome places Icebergs
- UNDERGROUND_STRUCTURES: Where Overworld Biomes place Dungeons and Fossils
- SURFACE_STRUCTURES: Where the Desert biome places Desert Wells
- STRONGHOLDS: No vanilla biomes place features here, but you can and it’ll work fine
- UNDERGROUND_ORES: Where all Overworld biomes place ores (which includes actual ore blocks, as well as the blobs of Dirt, Gravel, and Stone variants), as well as discs that generate on the floor underwater
- UNDERGROUND_DECORATION: Where all Nether biomes place ores (which includes actual ore blocks, as well as the blobs of Gravel and Blackstone), and where Overworld mountain biomes place blobs of Infested Stone
- FLUID_SPRINGS: Where all Overworld and Nether biomes place water and/or lava springs (individual fluid blocks that may or may not spill out of walls or ceilings)
- VEGETAL_DECORATION: Where all biomes place features such as trees, flowers, cacti, Huge Fungi, Chorus Plants and similar features
- TOP_LAYER_MODIFICATION: Where all Overworld biomes place a feature that causes snow or ice to cover the top blocks if the temperature is sufficiently low at that altitude
Important: If you have two or more features that appear in one step together (regardless of which step it is) in multiple biomes, they must always be in the same order, or the game will throw an error and fail to load (this is called a feature order cycle error). For the same reason, you can't repeat a feature in the same step, even one after the other, if that feature is used in a different biome.
Features are themselves composed of two other file types: placed_features, and configured_features. A configured_feature defines what type of feature it is, physically, such as an ore or a tree. The placed_feature determines under what conditions it spawns, such as in or on what blocks, at what Y level, or other factors. The placed_feature is what the biome file references.
Technically, the configured_feature can be defined in-line in the placed_feature, however it’s good practice to separate these files. This allows easier delineation when creating and editing -- as some configured_feature types include in-line placements like a placed_feature -- and also makes it easier to reuse a configured_feature in multiple placed_features.
Configured Features
There are many configured_feature types, each with different required fields. Listing each in detail would be unhelpful, outside the scope of this guide, and a duplication of efforts -- the wiki serves as a great reference to become familiar with the available feature types. As always, utilizing Misode to keep track of required fields is highly recommended. Furthermore, if you do have an idea of a vanilla feature that looks similar to what you want to create, referencing it or starting from it as a base, and then modifying it, is a completely valid strategy.Instead, what this section of the guide will go over is point out which features are best for what purpose, and which features are surprisingly difficult to work with, primarily as this knowledge may help keep you from becoming frustrated that you can’t figure out how to do something that is, in fact, not possible.
As mentioned above, some configured_features, like trees, offer a lot of control and flexibility. Trees have several different shapes to choose from for their trunks and leaves, as well as optional roots (such as what Mangroves have), options for decorations on any face of leaves, and can accept one or multiple different blocks to make up each of these facets.
The Ore feature type does not have quite as many fields, but still presents a good deal of configurability. Making a new ore configured_feature entails determining what the block being placed is (the state) and what blocks it tries to get placed in (the target), which can be a block tag. As you can see in the below example for Coal, you can also list multiple state and target pairs in one feature, which vanilla uses to place the appropriate Deepslate variant if the block it gets placed in is a Deepslate or Tuff Block rather than Stone or a stone variant.
The size is self-explanatory but is not indicative of the actual quantity of the state blocks that will be placed. More info on that relationship can be found on the wiki. Discard_chance_on_air_exposure is a chance between 0.0 and 1.0 to intentionally fail to spawn the feature if it touches air, such as in a cave. This is used in vanilla for so-called “buried” ore features like Iron and Diamonds, to encourage other forms of mining than just caving.
The Ore feature type is also what is used for the blobs of dirt, gravel, granite, tuff, and other blocks in the Overworld.
Moving into feature types that are not configurable and what you can do about it. End Islands, Basalt Pillars, Ice Spikes, Glowstone Blobs, and Coral Claws are all examples of features that have no configuration at all, meaning their shape and block palette is hardcoded. You can still change how they get placed with a placed_feature later, but you can’t change what these features physically are.
For cases like these where you may want to make use of those specific shapes, but can’t recreate them with other features (End Islands are a good example), you can create features to replace those blocks with other blocks in a later step. A good feature to use for this is netherrack_replace_blobs.
This just allows you to replace a target block with a state block in a 3D-diamond with a defined radius. It unfortunately doesn’t support block tags. It also has a maximum radius of 12, so you may need a higher quantity of them using your placed_feauture later to get consistent coverage.
Placed Features
A placed_feature typically references a configured_feature, and determines how it gets placed in the world. For some features, like Trees, they will obey wherever your placements happen to define as valid. For other features, like Ice Spikes, they need to adhere to hardcoded conditions of the feature type, which are not always obvious. Ice Spikes for example can only spawn on Snow Blocks, regardless of what the placed_feature says.As with the previous section, this guide will not go over every type of placement that can be included, nor every field they contain. These are all covered in detail on the wiki, and generating them can be aided using Misode.
However, there are a handful of placement types that are used extremely commonly, and so we will go over what those are, how to use them, and when they may not be needed.
Generally, placements are calculated in order from first to last. For some placement types, this is irrelevant, while for others, being listed before or after another placement can dramatically alter the spawning behavior. The following placement types are the most commonly used; a majority of placed_features will use some combination of these placements:
count: The number of spawn attempts this feature will make per chunk. Accepts a constant, or other number providers like uniform or trapezoid. If excluded, the placed_feature will make only 1 spawn attempt per chunk.
count_on_every_layer: An alternative to count. A little hard to explain, but essentially includes some random X and Z distribution, and Y distribution based on layers of air or fluid.
rarity_filter: Accepts a positive integer. Essentially divides any previous count-type placements by this value. For example, a rarity of 1 will cause no change, a rarity of 2 will make the feature half as common, a rarity of 5 will make it 5 times less common, etc. If no count-type placement was specified before this placement, the count is assumed to be 1.
in_square: This is used to include some random distribution within the chunk. Without this placement, all of the spawn attempts would be made at the chunk’s 0x, 0z coordinate. If you are using count_on_every_layer, you do not need to use in_square.
height_range: Determines the height this feature will try to spawn in. Accepts a constant, or other number providers like uniform or trapezoid.
- Whether using a constant or a number provider, each value must also be defined as “absolute” (this exact Y level), “above_bottom” (this many blocks above the lowest Y level of this dimension) or “below_top” (this many blocks below the highest Y level of this dimension, always a positive number). This allows some flexibility for situations such as if the height of the dimension may change or is unknown.
biome: Doesn’t have any other fields. Ensures that this feature won’t be allowed to spawn if the spawn attempt would be inside a biome that does not contain this placed_feature in its listed features. Without it, if a chunk contains two biomes, the feature would be allowed to “bleed” into the neighboring biome, even if it doesn’t belong there, as long as all other conditions are met (for example, a Desert’s Cactus feature spawning in an adjacent Beach biome).
block_predicate_filter: Can be used to apply one or more conditions based on nearby blocks, including the block that has been selected for the spawn attempt. This can include details like if the block below is solid or in a block tag, whether it has a sturdy face, or is a valid location for a sapling or mushroom to be placed.
One of the most important things to keep in mind when creating placed_features in particular is performance. More than anything else in worldgen, the placed_features are going to have the greatest impact on the speed of your chunk generation. Features that have a high count, or hyper-specific block_predicate_filters, can cause chunks to load more slowly. Similarly, including a height range for a feature that includes a lot of space that the feature can’t spawn in can impact this chunk generation, as all of those failed spawn attempts still have to be calculated.
Thanks for reading!
You made it to the end! If you want more help, or if you want to improve your skills more, please join our Discord community: https://discord.datapackhub.net/. We've got teams of people waiting to help you with any questions or projects you may have!| © 2024 kanokarob (Datapack Hub). Licensed under CC BY-SA 4.0 |
| Credit | This guide was written by kanokarob. SPECIAL THANKS: Misode for his incredible generators, without which much of this would be much more challenging! |
